Description
Operating Conditions
| Nominal pressure | PN 16 |
|---|---|
| Protection Class | IP 68 |
| Medium Temperature | 0.1 – 50°C |
| Environment Temperature | 1 – 70°C |
| Environment Class | C |
| Mechanical Class | M1 |
| Electromagnetical Class | E1 |
| Certification | MID2014/32/EU (ISO 4064) |
| Drinking Water Approval | ACS |
Communication Interfaces
| Pulse / RS 485 | Integrated 5 contacts M12 Connector |
|---|---|
| M-Bus |
Power Supply via integrated battery, cable length 1.5 m |
| wM-Bus | 434 MHz* or 868 MHz (OMS 3.0) |
| LoRa Sigfox |
868 MHz |
| NFC | Near Field Communication |
| LCD | 10 Digits |
Benefits for you
| Designed for robustness to dirt |
| Very high resistance for harsh environment |
| Accurate billing and monitoring enabled by a highly stable ultrasonic measurement over lifetime |
| Extendable battery lifetime up to 20 years with plug-in battery extension pack |
Product features
| Low pressure drop < 0.1 bar |
| Robust housing with flange interface |
| Performance / Class 2 |
| DN 50 to DN 150 |
| Battery Powered, lifetime up to 10 years / 20 years with battery extension pack |
